Description
TECHNICAL SPECIFICATION
GENERAL
Model
DSL5CR
Range
DSL
Technology
Valve
Channels
2 (Split)
ELECTRONICS
Output wattage
5W (with power reduction option, 0.5W)
Outputs
1 x 1/4" jack speaker output, 16Ω load only, 1 x 3.5mm jack emulated out
Inputs
1 x 1/4" jack instrument input, 3.5mm jack Aux in, footswitch
Controls
Classic gain channel (gain, volume), channel select, ultra gain channel (gain, volume), tone shift button, treble, middle, bass, deep EQ shift, reverb, low power option (on rear)
Effects
Digital reverb
Effects loop
Yes, series, send/return
SPEAKERS
Speaker configuration
1x10"
Speaker model
Celestion Ten-30 speaker (16Ω, 30w)
Unit impedance
16Ω
VALVES
Preamp valves
2 x ECC83
Power amp valves
1 x 12BH7
ACCESSORIES
Footswitch
PEDL-90012 included
Cable
Detachable power cable included
DIMENSIONS (INCLUDING FEET AND HANDLE)
Weight
12.7 kg / 28 lbs
Width
455 mm / 17.9"
Height
425 mm / 16.5"
Depth
240 mm / 9.4"
