Description
SPECIFICATIONS
Title Specification
Power Output: 0 to 200 watts, 4-8 ohms
AC Power Req.: 100-240Vac, 50-60Hz, 250W max
Input Connections: 1/4" mono, 2meg impedance.
Effects Loop: 1V full scale, 1K Send impedance, 47K Return impedance.
Direct Out (Rear): XLR-M, 300mv full scale, balanced, ground lifted, 10K min.
Signal Out (Front): TRS, switchable, Line Out pre-Master +4dB balanced, or Headphone post-Master.
Speaker 1 Output: 8 ohms, 200 W minimum recommended rating
Speaker 2 Output: 4 ohms, 200 W minimum recommended rating
Dimensions: 8.5" x 7.25" x 3.25" (21.6cm x 18.4cm x 8.3cm)
Weight: 3 lbs (1.5 kg)
