- SPECS
- neck typeWizard III7pc Maple/WalnutNeck-through
- top/back/bodyPoplar Burl (3mm) topAmerican Basswood body
- fretboardEbony fretboardAcrylic & Abalone block inlay
- fretJumbo Stainless Steel fretsPremium fret edge treatment
- number of frets24
- bridgeEdge bridge
- string space10.8mm
- neck pickupDiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
- bridge pickupDiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
- factory tuning1E,2B,3G,4D,5A,6E
- stringsD'Addario® EXL120
- string gauge.009/.011/.016/.024/.032/.042
- hardware colorGold
- NECK DIMENSIONS
-
- Scale :648mm/25.5"
- a : Width43mm at NUT
- b : Width58mm at 24F
- c : Thickness19mm at 1F
- d : Thickness21mm at 12F
- Radius :400mmR
